MRM Series
Quad Seal Bag Packaging Machine
Automatic Premade Pouch Rotary Filling & Sealing Machine
Capacity Up To 40 BPM
Bag Width 100 – 250mm / 4 – 9.8in
Filling Volume 10 – 2500g
Bag Length ≤ 350mm / 13.8in
As a special premade bag, Quad Seal Bag is usually difficult to use our machine to automate packaging. However, through the efforts of engineers, we have changed the shape of the machine clip and the automated process, optimized the operation of the cam, and made the Quad Seal Bag Packaging Machine possible. Now the Quad Seal Bag Packaging Machine, which has all the advantages of our rotary packaging machine, has officially come out.
Features
- Fully automatic rotary 8-station intermittent preformed bag dispensing, opening and closing.
- Versatile in design, easy to link up with other downstream packaging equipment such as liquid filler, multi-head weigher, metal detector, check weigher, case sealer, etc.
- Strict mechanical safety standards to ensure stable operation of machinery and increase packaging speed.
- Heavy parts are used to improve the durability of machinery.
- The simple design of the control system's touch screen facilitates the use of operators, and is simple and easy to use.
- Improve the solution, reduce the cost for you.
- The production line meets the requirements of food hygiene and is convenient to clean.
- Automatic control of a series of processes from loading, filling, sealing, and finished products.
- Automatic lubrication system.
- The new improvement makes it possible to pack the Quad Seal Bag.
Parameter
| MRM8-200 | MRM8-250 | |
|---|---|---|
| Bag Width | 100-200mm | 130-250mm |
| Bag Length | ≤ 350mm | ≤ 350mm |
| Filling Volume | 10-2500g | 10-2500g |
| Speed | Up to 40 Bags/Min | Up to 35 Bags/Min |
| Total Power | 3.3kw | 3.3kw |
| Dimension | 1460×2500×1400mm | 1710×1505×1640mm |
| Compressed Air | 0.6-0.8 m³/min | 0.6-0.8 m³/min |
Capacity & Filling Volume depends on the product status and filling weight.
Bag Style
- Liquid ——Detergent, Yellow rice wine, Soy sauce, Rice vinegar, Juice, Tomato paste, Peanut paste, Fruit paste, Chili sauce, Bean sauce, etc.
- Granule —— Crystal MSG, Granule medicine, Capsule, Seeds, Raw Chemistry material, Sugar, Chicken essence, Melon seed, Nuts, Pesticides, Fertilizer, Feed, etc.
- Powder —— Flavoring, MSG, Milk powder, Glucose, Washing powder, Raw chemistry material, White sugar, Pesticides, Fertilizer, etc.
- Solid —— Candy, Red dates, Oatmeal, Chocolate, Cookies, Peanut, Green soybeans, Rock candy, Pastry, Commodity, Puffed food, etc.
